Atech Water Level Sensor 4-20mA RS485 Liquid Level Transmitter Submersible Water Diesel Fuel Tank Level Sensor



Atech level sensors offer a comprehensive solution for monitoring and managing liquid levels in industrial tanks, reservoirs, wells, and other containment systems. These sensors are engineered to provide accurate measurements, easy integration, and robust performance in challenging conditions.

Atech level sensors provide a reliable, accurate, and durable solution for all your liquid level measurement needs, ensuring optimal performance and safety in diverse industrial applications.

Applications: *Water Treatment Plants: Monitoring water levels in tanks and reservoirs. *Oil and Gas Industry: Measuring levels of crude oil, refined products, and other fluids. *Chemical Processing: Managing chemical inventories and processing liquids. *Food and Beverage: Monitoring levels of ingredients and finished products.

*Pharmaceuticals: Ensuring accurate levels in production processes.



Water Treatment Plants
Oil and Gas Industry
Chemical Processing
Food and Beverage
Pharmaceuticals





Level range	0-0.5m…..500m H2O/ 0-0.05 Bar…..50 Bar
Overload	150% F.S.
Burst Pressure	500% F.S.
Accuracy	≤ ±0.5%F.S(Typical); ≤ ±0.25%F.S (by customized) @25 degree C
Long-term Stability	≤ ±0.1%F.S. of span/year
Working Temp.	-40℃~80℃(non-corrosive medium)
Storage Temp.	-40℃~80℃(Nitrile rubber sealing ring); -20℃~80℃(fluororubber rubber sealing ring)
Temperature Compensation	0℃~80℃
Medium compatible	Compatible with 316L Stainless Steel
Electronic Wire	2 Wires		3 wires				4 Wires
Output	4-20mA	4-20mA+Hart	0-5V	0-10V	0.5-4.5V	Dual 4-20mA	RS485
Power Supply	7-30Vdc	12-30Vdc	8-30Vdc	13-30Vdc	5Vdc	12-30Vdc	3.5-36Vdc
Electronic connection	Fixed cable with vented tube and water proof IP68
Response time	≤10 ms
Pressure Type	Gauge pressure; Sealed gauge and absolute optional.
Cable optional	PE Cable（Water Proof）; PU Cable（Oil/Fuel Proof）; FEP Cable（Anti-Corrosive）
