High-frequency radar level meter is installed on the top of the measured vessel, the antenna transmits electromagnetic waves, the electromagnetic waves reach the surface of the measured liquid solids are reflected back by the antenna to receive, the host computer through the measurement of the transmission and reception time t, according to the electromagnetic wave velocity v can be derived from the material surface to the antenna between the distance L, in the known flange or thread to the bottom of the vessel distance, that is, the installation of the height of the premise of H, you can convert to the containerlevel height h.
Calculation formula: h=H-L L=V*t/2
Rod type high-frequency radar level meter in a small amount of smoke and steam conditions of strong acid, alkali and other strong corrosive liquids in the measurement Measuring range of the conventional is 5 meters, can be done to 10 meters
Antenna length: 100mm, 200mm two kinds of
Temperature in the -30~130 ° C
Horn mouth high-frequency radar level meter for weak corrosive under the measurement of liquids, there can be temperature,Pressure
Measuring range is routinely within 20 meters, can do 30 meters
Flare length: 227mm, 228mm two kinds of
Temperature: room temperature type -30 ~ +130 ℃, medium temperature type -30 ~ +250 ℃, high-temperature type -30 ~ +400 ℃
