Products Description
The majority of Genset failures are “Failure To Start” errors. Much of the time this can be attributed to insufficient fuel. Fuel theft is also a problem for many generators, particularly those at remote site locations that are difficult to monitor and secure. Tank Depth Sensors can be deployed to tackle many of these common issues.
Product Features
●Monitor fuel level and know when to schedule refilling of the tanks.
●Monitoring of fuel level for sudden drops that could indicate leakage or theft.
●Graphing and record of fuel usage over time.
●Compare fuel usage with fuel delivery billing.
Product Specification
| Measurement Method | Hydraulic Pressure(Fluid column pressure) |
| Tank Depth | 0-20 m (65ft) for Water, 0-15m for Petrol, 0-16, 6 m for Diesel |
| Accuracy Distance | 0-2000 cm (65 ft) with 0.2% accuracy for water |
| Full-Scale Accuracy | +/-0.5% FS (Max) |
| Mounting | Suspended inside the tank by leader cable |
| Communications Cable | RJ45 jack to UFLS converter box using UTP Cat 5 wire |
| Communications Cable Max. length | 30 meters (100 ft) |
| Chemical Resistance | Petrol, Diesel, Water |
| Operating Temperature Rate | -20°C to 80°C |
| Protection Grade | IP68 (pressure sensor part) |
Product Dimensions
Product Features
●Monitor fuel level and know when to schedule refilling of the tanks.
●Monitoring of fuel level for sudden drops that could indicate leakage or theft.
●Graphing and record of fuel usage over time.
●Compare fuel usage with fuel delivery billing.
Product Dimensions
Product Specification
| Measurement Method | Hydraulic Pressure(Fluid column pressure) |
| Tank Depth | 0-20 m (65ft) for Water, 0-15m for Petrol, 0-16, 6 m for Diesel |
| Accuracy Distance | 0-2000 cm (65 ft) with 0.2% accuracy for water |
| Full-Scale Accuracy | +/-0.5% FS (Max) |
| Mounting | Suspended inside the tank by leader cable |
| Communications Cable | RJ45 jack to UFLS converter box using UTP Cat 5 wire |
| Communications Cable Max. length | 30 meters (100 ft) |
| Chemical Resistance | Petrol, Diesel, Water |
| Operating Temperature Rate | -20°C to 80°C |
| Protection Grade | IP68 (pressure sensor part) |
