Products Description
Compared with other types of weather stations, mechanical weather stations have some unique advantages. First, its structure is relatively simple and easy to maintain and operate. This allows it to maintain a stable working state in some remote areas or harsh environments. Second, the data quality of mechanical weather stations is usually higher because it relies on mechanical principles for measurement, avoiding errors and interference that may be caused by electronic components.
Product Features
● Low power consumption, 3.7-inch LCD screen
● Customized transmission, more convenient data viewing
● Support dual power supply of solar power supply/mains power supply
● Accurate data, real-time grasp of weather dynamics
● Free platform, real-time data viewing
● Remote monitoring, no need for dedicated personnel on duty
● Customized parameters, elements support customization
● Maintenance-free, corrosion-resistant, easy to integrate
● Wide range of applications, use in various working conditions
Product Specification
| Name | Measuring range | Resolution | Accuracy |
| Wind speed | 0~70m/s | 0.1m/s | ±(0.3±0.03V)m/s |
| Wind direction | 0~360° | 1° | ±3° |
| Atmospheric temperature | 50~+80ºC | 0.1ºC | ±0.2ºC |
| Relative humidity | 0~100%RH | 1%RH | ±3%RH |
| Soil temperature | 50~+80ºC | 0.1ºC | ±0.2ºC |
| Soil moisture | 0~100% | 1% | ±3% |
| Rainfall | 0~999.9mm | 0.2mm | ±4% |
| Total radiation | 0~2000W/M2 | 1 W/M2 | ±2% |
| Air pressure | 450~1060HP A | 0.1 HPA | ±0.3HPA |
| Evaporation | 0~100mm | 0.1mm | ±0.1mm |
| PM2.5 | 0~500UG/M3 | 1UG/M3 | ±5% |
| PM10 | 0~2000UG/M3 | 1UG/M3 | ±5% |
| Carbon dioxide | 0~2000ppm | 1 ppm | ±0.5% |
| Soil pH | 0~14pH | 0.1pH | ±0.2PH |
| sunshine | 0~200000lux | 10lux | ±5%F.S |
| Noise | 30~120dB | 0.1dB | ±1.5dB |
| Negative oxygen ions | 0-5000000pcs/CM3 | 0.1DB | ±1.5DB |
| Power supply system | Solar energy, DC, mains electricity, etc., optional | ||
| Communication System | RS232, RS485, USB, RJ45, GPRS, digital radio, etc., optional | ||
| Mounting Bracket | 2.5m galvanized pipe | ||
| Work Environment | -50~+50ºC,0~100%RH | ||
| Reliability | MTBF>6000 hours | ||
| Protection level | IP65, lightning protection, electromagnetic interference protection, salt spray corrosion protection | ||
| Time accuracy | Real-time clock, accuracy better than 20 seconds/month | ||
| Communication | GPRS/CDMA/satellite remote transmission center station and on-site direct connection | ||
Product Dimensions
Product Features
● Low power consumption, 3.7-inch LCD screen
● Customized transmission, more convenient data viewing
● Support dual power supply of solar power supply/mains power supply
● Accurate data, real-time grasp of weather dynamics
● Free platform, real-time data viewing
● Remote monitoring, no need for dedicated personnel on duty
● Customized parameters, elements support customization
● Maintenance-free, corrosion-resistant, easy to integrate
● Wide range of applications, use in various working conditions
Product Dimensions
Product Specification
| Name | Measuring range | Resolution | Accuracy |
| Wind speed | 0~70m/s | 0.1m/s | ±(0.3±0.03V)m/s |
| Wind direction | 0~360° | 1° | ±3° |
| Atmospheric temperature | 50~+80ºC | 0.1ºC | ±0.2ºC |
| Relative humidity | 0~100%RH | 1%RH | ±3%RH |
| Soil temperature | 50~+80ºC | 0.1ºC | ±0.2ºC |
| Soil moisture | 0~100% | 1% | ±3% |
| Rainfall | 0~999.9mm | 0.2mm | ±4% |
| Total radiation | 0~2000W/M2 | 1 W/M2 | ±2% |
| Air pressure | 450~1060HP A | 0.1 HPA | ±0.3HPA |
| Evaporation | 0~100mm | 0.1mm | ±0.1mm |
| PM2.5 | 0~500UG/M3 | 1UG/M3 | ±5% |
| PM10 | 0~2000UG/M3 | 1UG/M3 | ±5% |
| Carbon dioxide | 0~2000ppm | 1 ppm | ±0.5% |
| Soil pH | 0~14pH | 0.1pH | ±0.2PH |
| sunshine | 0~200000lux | 10lux | ±5%F.S |
| Noise | 30~120dB | 0.1dB | ±1.5dB |
| Negative oxygen ions | 0-5000000pcs/CM3 | 0.1DB | ±1.5DB |
| Power supply system | Solar energy, DC, mains electricity, etc., optional | ||
| Communication System | RS232, RS485, USB, RJ45, GPRS, digital radio, etc., optional | ||
| Mounting Bracket | 2.5m galvanized pipe | ||
| Work Environment | -50~+50ºC,0~100%RH | ||
| Reliability | MTBF>6000 hours | ||
| Protection level | IP65, lightning protection, electromagnetic interference protection, salt spray corrosion protection | ||
| Time accuracy | Real-time clock, accuracy better than 20 seconds/month | ||
| Communication | GPRS/CDMA/satellite remote transmission center station and on-site direct connection | ||
