Products Description
Radar level meter is a measuring instrument based on the time travel principle. Radar waves run at the speed of light, and the running time can be converted into a level signal through electronic components. The probe emits a high-frequency pulse that propagates at the speed of light in space. When the pulse encounters the surface of the material, it is reflected back and received by the receiver in the instrument, which converts the distance signal into a level signal.
Product Features
● High measurement accuracy, up to millimeter level
● Wide measurement range, suitable for harsh environments such as high temperature, high pressure, steam, dust, etc.
● Measurement is not affected by the properties, color, density, shape, etc. of the medium
● Simple installation, easy maintenance, long service life
Product Specification
Product Name | Split type radar level gauge |
Model Number | AFLSS-39 |
Detection range | 0.05-40m |
Operating Temperatures | -40~120ºC |
Working voltage | 3.3V,9-24v |
Output | TTL,RS485,RS232,3-wire 4-20mA Bluetooth,RJ45,2-wire 4-20mA Bluetooth |
Description | water level /oil lever sensor |
Theory | Distance Measuring Sensor |
Features | Radar sensor |
Product Dimensions
Product Features
● High measurement accuracy, up to millimeter level
● Wide measurement range, suitable for harsh environments such as high temperature, high pressure, steam, dust, etc.
● Measurement is not affected by the properties, color, density, shape, etc. of the medium
● Simple installation, easy maintenance, long service life
Product Dimensions
Product Specification
Product Name | Split type radar level gauge |
Model Number | AFLSS-39 |
Detection range | 0.05-40m |
Operating Temperatures | -40~120ºC |
Working voltage | 3.3V,9-24v |
Output | TTL,RS485,RS232,3-wire 4-20mA Bluetooth,RJ45,2-wire 4-20mA Bluetooth |
Description | water level /oil lever sensor |
Theory | Distance Measuring Sensor |
Features | Radar sensor |
