Water and Liquid Level Transmitter



This water and liquid level transmitter measures fluid level in tanks and wells and sends out a 0-10V signal proportional to the liquid depth. Stainless steel construction makes this sensor compatible with most any fluid.

The sensor is temperature compensated and operates accurately over all ambient temperatures.
The sensor head has a baffle to prevent debris buildup making it suitable where there is sludge and other solids mixed with the liquid. The polyurethane cable ensures long-term durability, while the stainless steel body protects against rust. Several models are available for tank depths from one to ten meters.



● Water level transmitter with 0-10V output
● Stainless Steel Construction, can be used for sensing liquid level in practically any fluid
● Full scale range of 1 to 10 meters in 1m increments.
● Digital powered sensor with temperature compensation.
● Non clogging design compatible with dirty fluids and sludge.
● Durable polyurethane cable
● Stainless steel construction with laser welded joints will not leak or corrode





Range	10000mm, 1000mm, 2000mm, 3000mm, 4000mm, 5000mm, 6000mm, 7000mm, 8000mm, 9000mm
Output type	0~10V, 4~20mA
Accuracy	0.5% full scale
Power Supply	12~36VDC
Temperature Range	-20~60℃
Measuring medium	The fluid in the open container (compatible with the contact material), can be customized PTFE anticorrosion
Contact material	Diaphragm 316L stainless steel (in contact with media) Probe housing 304 stainless steel (default)
Liquid level range	0~0.5 m ~1000 m (each gear of the range is optional)
Working mode	Static pressure type, input type
Output signal	to 20mA(delivered by default), 0 to 10V, 0 to 5V, 1 to 10V, 1 to 5V0.5 to 4.5V(customized), RS485 power supply voltage :12 to 36VDC(default), 5VDC(customized)
Accuracy	0.5% full scale
Working condition	Medium temperature -10~50℃(non-crystallization) ambient temperature -20~60℃ Temperature compensation -10~70℃
Seismic performance	10g(202000HZ)
Response frequency	Analog signal output <100Hz(default)
High-frequency customization	1200Hz, 2400Hz stability :±0.1%FS/ year
Temperature drift	±0.02%FS/℃(within the temperature compensation range)
Class of protection	IP68 Maximum power :≤0.5(W)
