Products Description
Description:
wireless level transmitter adopts micro-power wireless communication mode, no wiring is required, installation is faster, safer and more convenient. It has built-in high-precision pressure sensor, which can accurately display the pressure in real time, and has the characteristics of high stability and long-term stability. This type of digital level gauge is equipped with large-scale HD LCD display and built-in MCU. With mature GFSK/Lora/4G/IOT network, the on-site pipeline pressure is uploaded to the data center.
Or, it can be matching with wireless switching device, which can convert many wireless pressure signals into MODBUS standard signals and transmit them through Ethernet or serial port.
Applications:
- Hydraulic monitoring
- Variable frequency water supply
- Liquid level measurement in petroleum and metallurgy industries
- Urban water supply
- Sewage treatment
- Tank level monitoring
- Water-saving irrigation
- Circulating fluid monitoring
Product Features
- Wide application range
- Long service life
- Diffused silicon oil-filled sensor core
- CE certified
- Optional reinforced anti-corrosion cable
- Intrinsically safe & explosion-proof design
- Fully sealed, water and corrosion resistant
- Strong anti-interference capability
- Adaptable to various media working conditions
- Easy and efficient installation & maintenance
Product Specification
| Range | 0m~0.5m…300m |
| Overload capability | ≤ 2 times full scale |
| Pressure Type | G (gauge pressure), A (absolute pressure) |
| Accuracy | 0.1% (custom), 0.25% (typical), 0.5% (maximum) |
| Long-term stability | ±0.1%FS/year (typical), ±0.2%FS/year (maximum) |
| Zero temperature drift | ±0.03%FS/°C, ±0.02%FS/°C |
| Sensitivity temperature drift | ±0.03%FS/°C, ±0.02%FS/°C |
| Compensation temperature | 0°C~50°C(typical), -10°C~65°C |
| Working temperature | -30°C~80°C |
| Power supply | 38000 mAh disposable lithium battery |
| Sensor chip | German chips approved by Semtech |
| Output Signal | Lora/4G/NB-IOT/GFSK SWSN |
| Reporting period | 1 minute-12 hours (Can be set freely) |
| Display | 4-digit LCD, 0~3 decimal point can be set |
| Transmission power | ≤ 40mW |
| Protection level | IP68 |
| Explosion-proof grade | II 1G Ex ia da op is IIC T4 Ga |
| Process interface: | customized according to customer requirements |
